High Performance, Compact Imaging Cameras
Quantum Design UK and Ireland are really pleased to be able to offer three incredible Specim Hyperspectral Imaging Cameras and the ImageIR 8300 from InfraTec to researchers.
Specim is a pioneer and world leader in hyperspectral imaging instrumentation. With a hyperspectral imaging camera from Specim you will have spectral information at each and every pixel of your image.
The 2D infrared (IR) cameras from InfraTec are suitable for all applications of thermography. By using an IR camera one can perform non-contact absolute (or relative) temperature measurements, which allows – for example – non-destructive object inspection.
Which one is for you?
About the Specim FX10
The FX10 is a compact, lightweight, cost-effective hyperspectral camera for the VNIR spectral range (400-1000 nm). F/1.7 optics enables excellent light throughput, high sensitivity, short integration times and high signal-to-noise ratio. The FX10 operates with an impressive frame rate of 330 fps (full frame) using 1024 spatial pixels and 220 spectral bands. By reducing the number of spectral bands, the frame rate can be increased up to 9,900 fps. The camera is supplied with a high quality lens (38 deg FOV) and includes an integrated shutter and order sorting filter. The camera is also IP52 rated, making it suitable for use in harsh environments.
FEATURES:
- 400-1000 nm spectral range
- 5.5 nm spectral resolution
- 220 spectral bands
- F/1.7 optics
- 1024 spatial pixels
- 330 fps (full frame)
- CL or GigE models
- 600:1 SNR (peak)
APPLICATIONS:
- Vegetation & agriculture
- Phenotyping
- Colour & density in printing
- Display & light source inspection
- Food quality
About the Specim FX17
The FX17 is a small footprint hyperspectral camera built around an InGaAs detector. It operates in the NIR spectral range (900-1700 nm). As with the FX10 camera, F/1.7 optics enables excellent light throughput, high sensitivity, short integration times and high signal-to-noise ratio. The FX17 operates with a frame rate of 670 fps (full frame) using 640 spatial pixels and 230 spectral bands. By reducing the number of spectral bands, the frame rate can be increased up to 15,000 fps. The camera is supplied with a high quality lens (38 deg FOV) and includes an integrated shutter. The camera is also IP52 rated, making it suitable for use in harsh environments.
FEATURES:
- 900-1700 nm spectral range
- 8 nm spectral resolution
- 230 spectral bands
- F/1.7 optics
- 670 fps (full frame)
- CL or GigE models
- 1000:1 SNR (peak)
APPLICATIONS:
- Feed Quality
- Waste Sorting
- Recycling
- Moisture Measurement
- Threat detection, Security
About the Specim IQ
The Specim IQ is a portable hyperspectral camera, where data capturing, data processing and result visualisation are integrated into a one ready-to-use package. The camera is able to screen the imaging target and show the results on the camera display in just seconds.
FEATURES:
- VNIR 400-1000 nm (CMOS)
- 5 Mpix
- SD card max 32 GB
- Specim Dataset with ENVI compatible data files
- 5200 mAh Li-Ion (Type 26650)
- Appx. 100 measurements with one SD card and battery
- 4.3 ” touch screen + 13 physical buttons
APPLICATIONS:
- Art Conservation
- Food Fraud Detection
- Forensics
- Baked Goods Quality
- Automotive Industry
- Meat Inspection
- Agriculture
About the InfraTec ImageIR 8300
FEATURES:
- Full-frame rate up to 355 Hz in the format (640 × 512) IR pixels
- Opto-mechanical MicroScan with (1,280 × 1,024) IR pixels
- Outstanding thermal resolution better than 20 mK
- Integrated trigger interface guarantees a repeatable high-precision triggering of quick procedures
APPLICATIONS:
- Analysis of Tensile Stress Samples
- Laser Based Production
- Automotive Industry
- Electronics
- Metallurgy
- Chemical Industry
- Aerospace
- Glass Industry
Are you interested in securing one of these cameras for your next project? If you have any questions, please get in touch with our Technical Sales Engineer, Dr. Luke Nicholls (01372) 378822 or email him.
