Lake Shore Janis Superconducting Magnet Systems
Superconducting Magnet Systems
With over four decades of experience and a worldwide installation base, Lake Shore (Environment by Janis) is a recognised leader in the design and manufacture of superconducting magnet systems. Janis’ renowned SuperVariTemp insert operates from 1.5 K to 325 K, and is featured in the SuperVariMag, OptiMag and SuperOptiMag systems and is also available as an independent insert for use with existing magnets. Lake Shore also offers a variety of superconducting magnet systems that offer a room temperature bore (with inserts that reach 800 K), along with a variety of other systems that are designed for specific applications. These state of the art systems feature integrated designs for the cryostat, magnet, temperature controller and programmable power supply, together with a complete line of ancillary equipment. Their approach to superconducting magnet system design provides a variety of technical and cost benefits.
By maintaining flexibility over the specification and integration of the magnet, electronics, temperature controller, and cryostat, Lake Shore is able to offer magnet systems with performance characteristics tailored to individual experimental and budgetary requirements.
For more information please visit Lake Shore Cryotronics
STANDARD SYSTEM FEATURES:
- Top sample loading and exchange at all temperatures
- Effortless sample rotation and translation about the vertical axis at all temperatures, with options for rotation about a horizontal axis
- Field-independent thermometry
- The SuperVariTemp system, with provision for a temperature control thermometer at the heat exchanger
- Vapour cooled/superconducting high current magnet leads
- Superconducting magnets with persistent mode operation providing field stabilities of 20 ppm/h
- Carefully designed magnet support inside the helium reservoir, with optical access through the Dewar vacuum space (OptiMag and SuperOptiMag systems)
- Built-in superconducting liquid helium level sensors, providing continuous or timed level monitoring
- Readily accessible and interchangeable sample chambers
COMPLETE SYSTEMS INCLUDE:
- Programmable magnet power supply with computer interface and bi-polar operation
- Temperature controller with field independent thermometry
- Liquid helium transfer lines
- Cryogenic Hall probe and gaussmeter
- Automatic nitrogen filling mechanism
- Vacuum pumping stations
Profile
Profile
Profile
Profile
Profile
Profile
Profile
Superconducting Magnet System Specifications
Please see individual systems for their specifications:
